Construction
Conductor: 24 AWG Solid Bare Copper
Number of Conductors or Pairs: 4 Pair
Jacket Material: Polyvinyl Chloride
Nominal Overall Cable Diameter: 0.185 inch (4.699 mm)
Approximate Cable Weight: 20 lb (1,000ft)
Electrical & Physical Properties
Temperature Rating: 0 degrees celsius to 50 degrees celsius (installation); -10 degrees celsius to 60 degrees celsius (operation)
Velocity of Propagation: 70%
Mutual Capacitance: 14 pF/ft Nominal
Capacitance Unbalance: 330 pF/ft maximum
Maximum Conductor D.C.R.: 28.6 ohm/1,000 ft
Maximum D.C.R. Unbalance: 5%
Maximum Delay Skew: 45.0ns/100m
Maximum Propagation Delay Skew: 5.7ns/100m
Maximum Installing Tension: 25 lbs
Minimum Bending Radius: 1 inch
