Taramps DS 800X4 Class D 4 Channels 2 Ohm 800 Watts RMS Full Range Audio Amplifier

The DS 800×4 is a synonym for Taramps multichannel amplifier module. It has 4 channels of 200 Watts RMS, with maximum power of 800 Watts RMS, impedance of 2 ohm and is compatible with any frequency, that is, it is FULL RANGE. Versatility, efficiency and quality in a single Taramps product.

Features

  • Number of Channels: 4
  • Maximum Power:
  • @ 12,6 VDC - 1 OHM: 800W RMS (4 x 200W RMS)
  • @ 12,6 VDC - 2 OHMS: 544W RMS (4 x 136W RMS)
  • Signal Noise/Ratio: >88dB
  • Frequency Response: 10Hz ~ 45KHz (-3dB)
  • Input Impedance: 18K OHMS
  • Minimum Supply Voltage: 9 VDC
  • Maximum Supply Voltage: 16 VDC
  • Idle Consumption: 1.0A
  • Maximum Musical Power: @ 12.6 VDC: 51A
  • Maximum Sine Signal Consumption: (1KHz) 12.6VDC: 102A
